• Wheels: 16" Steel w/Black Center Hubcap
• Tires: 235/65R16C AS BSW
• Wheels w/Silver Accents w/Hub Covers
• Steel Spare Wheel
• Full-Size Spare Tire Stored Underbody w/Crankdown
• Black Front Bumper
• Black Rear Step Bumper w/1 Tow Hook
• Black Bodyside Cladding and Black Wheel Well Trim
• Black Side Windows Trim and Black Front Windshield Trim
• Black Door Handles
• Black Power Side Mirrors w/Convex Spotter and Manual Folding
• Fixed Rear Window
• Light Tinted Glass
• Variable Intermittent Wipers
• Fully Galvanized Steel Panels
• Black Grille
• Split Swing-Out Rear Passenger Side Door
• Split Swing-Out Rear Cargo Access
• Tailgate/Rear Door Lock Included w/Power Door Locks
• Reflector Halogen Headlamps

• Radio: AM/FM Stereo -inc: (18), digital clock and audio input jack
• Radio w/Seek-Scan and Clock
• 6 Speakers
• Fixed Antenna
• 1 LCD Monitor In The Front

• Pewter Vinyl Dual Bucket Seats -inc: 2-way manual driver seat, 2-way manual passenger seat and driver armrest
• 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
• 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
• Bench Front Facing Vinyl Rear Seat
• Manual Tilt/Telescoping Steering Column
• Fixed Rear Windows and Fixed 3rd Row Windows
• Fixed Split-Bench Vinyl 3rd Row Seat Front, 3 Manual and Adjustable Head Restraints
• Removable Split-Bench Front Facing 4th Row Seat Number, Control and Type Head Restraint
• Front Cupholder
• Rear Cupholder
• Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry and Panic Button
• Manual Air Conditioning
• Rear HVAC
• HVAC -inc: Underseat Ducts, Auxiliary Rear Heater and Headliner/Pillar Ducts
• Locking Glove Box
• Driver Foot Rest
• Interior Trim -inc: Metal-Look Instrument Panel Insert
• Full Cloth Headliner
• Urethane Gear Shifter Material
• Vinyl Front Bucket Seats
• Day-Night Rearview Mirror
• Partial Floor Console w/Storage and 3 12V DC Power Outlets
• Front Map Lights
• Fade-To-Off Interior Lighting
• Full Vinyl/Rubber Floor Covering
• Vinyl/Rubber Floor Trim
• Cargo Space Lights
• Instrument Panel Bin, Driver / Passenger And Rear Door Bins
• Power 1st Row Windows w/Driver 1-Touch Down
• Power Door Locks w/Autolock Feature
• Analog Appearance
• Seats w/Vinyl Back Material
• Manual Adjustable Front Head Restraints and Manual Adjustable Rear Head Restraints
• Driver Armrest
• 3 12V DC Power Outlets

• AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC)
• ABS And Driveline Traction Control
• Side Impact Beams
• Dual Stage Driver And Passenger Seat-Mounted Side Airbags
• Low Tire Pressure Warning
• Dual Stage Driver And Passenger Front Airbags
• Safety Canopy System Curtain 1st, 2nd And 3rd Row Airbags
• Airbag Occupancy Sensor
• Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners
• Back-Up Camera

CHARCOAL BLK CLOTH DUAL BUCKET SEATS W/PWR DRIVER

• 10-way power heated driver seat w/lumbar
• 2-way manual passenger seat and driver and passenger armrest

RADIO: AM/FM STEREO W/SINGLE CD/SYNC

• (21)
• 4" multi-function display
• message center (level 1 instrument cluster) and 6 speakers (2 front/4 rear)
• SYNC Communications & Entertainment System
• 911 Assist
• VHR
• SYNC Services
• AppLink
• Bluetooth®
• steering wheel controls
• USB port and auxiliary input jack
• Vinyl Sun Visors
• illuminated vanity mirrors

CNG/PROPANE GASEOUS ENGINE PREP PACKAGE

• hardened engine intake and exhaust valves
• Note: This package does not include CNG/propane fuel tanks
• lines
• etc
• Vehicle will be equipped w/the standard factory gasoline fuel system
• Additional equipment combined w/a certified calibration reflash is required
• from an external upfitter
• to convert the vehicle to a CNG/propane-fueled vehicle
• Ford Motor Company does not provide an exhaust or evaporative emissions certificate w/this option when converted to use CNG or propane fuel
• Ford does not represent that a vehicle converted to use CNG or propane will comply w/all applicable U.S
• or Canadian safety standards
• It is the responsibility of the final stage manufacturer (body-builder
• installer
• alterer or subsequent stage manufacturer) to determine that any vehicle converted to use CNG or propane complies w/U.S
• Federal
• California or Canadian exhaust and evaporative emission requirements
• Federal fuel economy standards
• U.S
• and Canadian safety standards
• labeling and other requirements

TOW/HAUL MODE W/TRAILERING WIRING PROVISIONS

• trailer wiring harness to rear of vehicle for upfit
• Trailer Sway Control (TSC)
• 4/7 pin connector assembly and rear jumper
• Note: This package does not include a Trailer Brake Controller (67D)
• Additionally
• if customer wants a trailer brake controller after initial purchase
• it will have to be an aftermarket trailer brake controller and aftermarket wiring harness

MODIFIED VEHICLE WIRING SYSTEM

• modified vehicle connections for customized wiring harness provisions

• Order Code 302A: Cloth Front Bucket Seats; AM/FM single-CD Stereo; 3.73 Axle Ratio; 6-Speed Automatic Transmission with Overdrive and SelectShift; Vinyl Sun Visors; 235/65R16C AS BSW Tires; Cruise Control with Message Center; 9
• 000 lbs GVWR; 16" Steel Wheels with Full Silver Cover; 3.7L Ti-VCT V6 Engine; Pewter Cloth Dual Bucket Seats; Exterior Upgrade Package
• RV Prep Package: Front Only Carpet Floor Covering; Front Headliner; Privacy Glass; Modified Vehicle Wiring System; Tow/Haul Mode with Trailering Wiring Provisions; 2-Passenger Seats; Front License Plate Bracket
• Charcoal Black Cloth Dual Bucket Seats with Power Driver
• AM/FM Stereo with Single CD/SYNC
• 3.73 Limited-Slip Axle Ratio
• CNG/propane Gaseous Engine Prep Package
• Tow/Haul Mode with Trailering Wiring Provisions
• Tinted Glass
• Back Up Alarm
• Modified Vehicle Wiring System
• Rear mounted camera
• Brake assist system
• Selective service internet access
• Cruise control with steering wheel mounted controls
• Heated driver seat
• Driver seat power reclining
• lumbar support
• cushion tilt
• fore/aft control and height adjustable control
• 3.7L V-6 DOHC
• Ti-VCT variable valve control
• engine with 275HP
• 3.7L V-6 DOHC
• Mechanical
• Bluetooth® wireless audio streaming
• Bluetooth® handsfree wireless device connectivity
• Smart device app link
• Trailer sway control
• SYNC external memory control
• AdvanceTrac w/Roll Stability Control electronic stability control system with anti-roll
• Hill start assist
• 3 12V power outlets
• Rain detecting wipers
• 911 Assist emergency SOS system via mobile device
• Gauge cluster display size: 3.00
• Manual tilting steering wheel
• Manual telescopic steering wheel
• Capless fuel filler
• Full wheel covers
• 16 x 7-inch front and rear steel wheels
• LT235/65SR16 AS BSW 720 RPM front and rear tires
• Cloth front seat upholstery
• 6 airbags
• Driver front impact airbag
• Seat mounted side impact driver airbag
• Curtain first-row overhead airbags
• Passenger front impact airbag
• Seat mounted side impact front passenger airbag
• Airbag occupancy sensor
• Auto-locking doors
• 6-speed automatic
• Selectable mode transmission
• Manual climate control
• Back-up alarm
• Transmission electronic control
• SelectShift Sequential shift control
• Automatic
• Reflector headlights
• Halogen headlights
• Auto on/off headlight control
• Bucket front seats
• Driver seat with 8-way directional controls
• Front passenger seat armrest
• Front passenger seat with 4-way directional controls
• 4-wheel disc brakes

• Vehicle
• Rear Door Type: Split Swing-Out
• Electrical
• Maximum Alternator Capacity (amps): 150
• Weight Information
• Base Curb Weight (lbs): 6036
• Base Curb Weight (lbs): 6038
• Base Curb Weight (lbs): 6034
• Gross Axle Wt Rating - Front (lbs): 4130
• Gross Axle Wt Rating - Rear (lbs): 5730
• Curb Weight - Front (lbs): 3105
• Curb Weight - Rear (lbs): 2929
• Gross Vehicle Weight Rating Cap (lbs): 9000
• Gross Combined Wt Rating (lbs): 10800
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4200
• Dead Weight Hitch - Max Tongue Wt. (lbs): 420
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4200
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 420
• Maximum Trailering Capacity (lbs): 4200
• Suspension
• Suspension Type - Front: Strut
• Suspension Type - Rear: Leaf
• Spring Capacity - Front (lbs): 4130
• Spring Capacity - Rear (lbs): 5730
• Axle Type - Front: Independent
• Axle Type - Rear: Rigid Axle
• Axle Capacity - Front (lbs): 4130
• Axle Capacity - Rear (lbs): 5515
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Brakes
• Brake Type: 4-Wheel Disc
• Brake ABS System: 4-Wheel
• Brake ABS System (Second Line): 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.1
• Rear Brake Rotor Diam x Thickness (in): 12.1
• Tires
• Front Tire Size: LT235/65SR16
• Rear Tire Size: LT235/65SR16
• Spare Tire Size: Full-Size
• Front Tire Capacity (lbs): 6394
• Rear Tire Capacity (lbs): 5996
• Revolutions/Mile @ 45 mph - Front: 720
• Revolutions/Mile @ 45 mph - Rear: 720
• Wheels
• Front Wheel Size (in): 16 X 7
• Rear Wheel Size (in): 16 X 7
• Spare Wheel Size (in): Full-Size
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Rack-Pinion
• Turning Diameter - Curb to Curb (ft): 48
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 25
• Doors
• Side Door Type: Split Swing-Out
• Exterior Dimensions
• Wheelbase (in): 147.6
• Length, Overall (in): 237.6
• Width, Max w/o mirrors (in): 81.3
• Height, Overall (in): 82.4
• Ground to Top of Load Floor (in): 28.8
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 2 (in): 141.7
• Cargo Area Width @ Beltline (in): 69.8
• Cargo Box Width @ Wheelhousings (in): 53.7
• Cargo Box (Area) Height (in): 52.8
• Cargo Volume to Seat 1 (ft³): 285.9
• Cargo Volume to Seat 3 (ft³): 78.2
• Cargo Volume to Seat 4 (ft³): 78.2
• Interior Dimensions
• Passenger Capacity: 12
• Front Head Room (in): 40.8
• Front Leg Room (in): 39.7
• Front Shoulder Room (in): 67.9
• Front Hip Room (in): 67.5
• Second Head Room (in): 41.1
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 71.4
• Second Hip Room (in): 69.6
• Third Head Room (in): 40.6
• Third Leg Room (in): 35.6
• Third Shoulder Room (in): 67
• Third Hip Room (in): 67.3
• Summary
• Vehicle Name: Ford Transit Passenger Wagon
• Body Style: Low Roof Passenger Van
• Body Code: V
